Tugboat Kalle 2 1/20

Aero-Naut 3032/00

New version 2022

The Kalle 2 is an evocation of a small steam tugboat in 1/20 scale, typical of the tugs of the 1920s-1930s.

The kit features the latest laser-cutting technology and high-precision fitting. The hull is made from thermoformed plastic, while the superstructures are made from laser-cut wooden parts. High-quality photo-etched brass parts enable the model to be finely detailed.

The voluminous hull provides ample space for the installation of an RC package. A smoke generator can also be fitted.

The model can be fitted with an optional lighting system. The kit can be powered by a conventional brush motor or a brushless outrunner motor.

The kit includes :

• A large thermoformed plastic hull
• High-precision laser-cut wooden parts
• Machined and engraved brass parts
• Propeller shaft and stern tube
• Ø50mm three-blade plastic propeller
• Fittings such as blower, lifebuoy, fenders, towing hooks and lights
• A cradle
• Complete 3D assembly instructions (French assembly instructions available in the "Download" section above)

Features :

• Length: 720mm
• Width: 220mm
• Height: 470mm
• Scale: 1/20
• Weight: 3.3kg

Equipment required for navigation to be supplied separately (see "accessories" below):

• Minimum 2-channel radio control system
• Servo control for rudder
• 7.2V NiMh or 7.4V LiPo 2S battery

• Conventional motorization
  • Poison motor ref: PCCAC500906023
  • Aquaspeed 50 ref: VATMT6830
  • Ø3.17/Ø4mm coupling ref: ACTH20036
  • 3-blade brass propeller Ø50mm (optional) ref: PBRA214618

• Brushless motor

  • Brushless motor Ø28mm Actro-N 28-4-880 réf : MOAE700304
  • Actro-Marine 30A brushless controller ref: VAAE700342
  • Ø4/Ø4mm coupling ref: ACTH20023
  • 3-blade brass propeller Ø50mm (optional) réf : PBRA214618
